Rubber Timing Belt
Industiral TM Belt, Automotive TM Belt, Double-sided TM Belt, Coated TM Belt,
Open Ended One-sided TM Belt, Extra Long Length TM Belt
PU Timing Belt
Open Ended Belt, Welded Belt, Polyurethane Endless Belt (PU V-ribbed Belt)
Feature
•It may solve the problems like low transmission efficiency and lubrication oil required under the status of high speed.
•Glass fiber as tensile member, no elongation of rubber belt.
•Excellent heat-resistance, oil-proof and wearing resistance.
Section Size of T type Synchronous Belt
|
Section |
Type |
Pitch (mm) |
Tooth Height (h, mm) |
Belt Thickness (H, mm) |
Angle (a) |
|
|
MXL |
2.032 |
0.51 |
1.14 |
40° |
|
XXL |
3.175 |
0.76 |
1.52 |
50° |
|
|
XL |
5.08 |
1.27 |
2.30 |
50° |
|
|
L |
9.525 |
1.91 |
3.60 |
40° |
|
|
H |
12.7 |
2.29 |
4.30 |
40° |
|
|
XH |
22.225 |
6.35 |
11.20 |
40° |
|
|
T5 |
5 |
1.2 |
2.2 |
40° |
|
|
T10 |
10 |
2.5 |
4.5 |
40° |
Section Size
of Arc Tooth Industrial Synchronous Belt
|
Section |
Type |
Pitch (mm) |
Tooth Height (h, mm) |
Belt Thickness (H, mm) |
Angle (a) |
|
|
HTD-3M |
3 |
1.71 |
2.4 |
/ |
|
HTD-5M |
5 |
2.06 |
3.8 |
/ |
|
|
HTD-8M |
8 |
3.36 |
6 |
/ |
|
|
HTD-14M |
14 |
6.02 |
10 |
/ |
|
|
HTD-20M |
20 |
8.4 |
13.2 |
/ |
|
|
STPD/STS-S3M |
3 |
1.14 |
1.9 |
/ |
|
|
STPD/STS-S4.5M |
4.5 |
1.71 |
2.81 |
/ |
|
|
STPD/STS-S5M |
5 |
1.91 |
3.4 |
/ |
|
|
STPD/STS-S8M |
8 |
3.05 |
5.3 |
/ |
|
|
STPD/STS-S14M |
14 |
5.3 |
10.2 |
/ |
|
|
RPP/HPPD-2M |
2 |
0.76 |
1.36 |
/ |
|
|
RPP/HPPD-3M |
3 |
1.15 |
1.9 |
/ |
|
|
RPP/HPPD-5M |
5 |
1.95 |
3.5 |
/ |
|
|
RPP/HPPD-8M |
8 |
3.2 |
5.5 |
/ |
|
|
RPP/HPPD-14M |
14 |
6 |
10 |
/ |
